Mi9 Single Bellcrank Conversion
Mi9 Single Bellcrank Conversion
Regular price
$60.00 CAD
Regular price
Sale price
$60.00 CAD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Adjustable Single Bellcrank conversion for better Ackerman tuning options
For settings:
Towards the front of the car is more aggressive
Middle is fairly neutral feeling
And towards the rear of the car will be a bit more numb feeling
*Note, the ballstuds have a shoulder on the thread, they must sit in the counterbore side of the bellcrank or you will snap it off!
Some shimming may be required as the U4689 shim thickness is not always consistent
The following Not Included but Required
2 M3x8 FHCS (Secure bridge to chassis)
2 M3x5 BHCS (Secure post to bridge and bellcrank to post)
2 - 4x8x3 bearings
Inner Diameter : 4mm
Outer Diameter : 8mm
Thickness : 3mm
1 - U4689 (Standoff Bushing and Bearing Spacer)
